* JBL CLUB A1000 - Mono Subwoofer Amplifier 1000w RMS

THIS ITEM IS NO LONGER AVAILABLE

JBL CLUB A1000 - Mono Subwoofer Amplifier 1000w RMS

The JBL Club A1000 mono subwoofer amplifier delivers 1000-Watts RMS using a Class D amplifier design to ensure high output and minimum current draw. Speaker-level inputs allow this amplifier to integrate into almost any system, even one using your car's factory radio. You can use the low-pass filter and variable bass boost to maximize the performance of your subwoofer and enclosure, while a phase switch ensures that the bass will blend well with your full-range speakers.

Features

• Compact size
• High and low level input
• Variable crossover and bass boost
• Low noise and distortion
• Input Level Control
• Full on-board protection
• Phase Switch
• RBC wired remote
• Strappable for up to 2,000 watts of power at 4 ohms
• Class D amp technology
• Turn-on mode

Specifications

• Mono subwoofer car amplifier
• 600 watts RMS x 1 at 4 ohms
• (1000 watts RMS x 1 at 2 ohms)
• Class D amp technology
• Frequency response: 10–320Hz
• Variable low-pass filter (32–320Hz,
• 12dB/octave)
• Variable bass boost (0-12dB at 45Hz)
• Phase switch (0, 180 degrees)
• Wired remote level control included
• Preamp inputs and outputs
• Speaker-level inputs (speaker wire-to-RCA adapters included)
• 4-gauge power and ground leads recommended — wiring and hardware not included with amplifier
• Fuse rating: 35A x 3
• W x H x D = 320mm x 51.3mm x 180mm
• W x H x D = 12-5/8" x 2-1/16" x 7-1/8"

What’s in the box:

• One Club A1000 mono subwoofer car amplifier
• Six 35A ATO fuses (3 installed, 3 spare)
• 2 Bare wire-to-RCA adapters
• Remote bass control module
• 16.5' Remote control cable (RJ-25 plugs on both ends)
• 2 Self-tapping screws for remote (M3 x 15mm)
• 4 Mounting screws (M4 x 53mm)
• Owner’s Manual
• Two JBL stickers
• 1 logo badge

Optional

• 4 Gauge Amp Kit

1. Due to continuous product improvement, specifications, pricing and design are subject to change without notice.
